Castaly WP-2000 20" Heavy Duty Planer

Heavy cast iron one-piece frame and base.

Easy and accurate assembly of the knives.

High quality for long period of use.

Top rollers for returning stock.

Table raises and lowers easily.

Gear driven feed rollers for trouble free feeding.

Sealed long-life ball bearings.

Precision three knives cutter head.

Heavy-duty precision ground cast iron stable.

Fast 30 FPM for mass production performance.

3 Belts drive for full power transfer.

Industrial motor for durability usage.

Anti-kickback fingers for safety protection.

SPECIFICATIONS WP-2000

Table Area 21" x 28"

Max. Planing Width 20"

Max. Planing Thickness 7"

Min. Planing Thickness ½"

Cutter Head Speed 5500 RPM

Cutter Head Dia. 3-1/8"

Knife Dimensions (T x W x L) 1/8" x 1-1/8" x 20"

Feeding Speed 30 FPM

Max. Cutting Depth ¼"

Min. Planing Length 10"

Motor 3 HP, 1 PH, 230 V

N.W. 850 LBS

G.W. 1100 LBS
