Castaly BR-3242U c. 1 Ver. 1 Universal x 21 Drills Two Line Boring

The machine is standard design and constructed for Horizontal and Vertical Boring units.

The left-side 21 vertical drills, drill head can be adjusted to any degree position for vertical or horizontal axis combination construction drill. (21-2121U One 21 Drill Head, BR-2142U Two 21 Drill Head).

The machine is easy to operate. Simply press the foot switch and entire horizontal and vertical boring operations can be accomplished by pneumatic power.

Vertical boring for drilling at longitudinal and cross directions. The left-hand side vertical boring units can be tilted from vertical to horizontal position by pneumatic piston.

The vertical boring units can be adjusted up & down and right & left. Readouts are provided for accurate indication of adjustment.

An emergency switch is provided on the top beam, allowing the operator to stop the machine conveniently.

The panel clamp position is adjustable.

Square slide way for vertical boring unit, providing maximum rigidity and stability for boring operations.
