Vitap Alpha 27 Construction Boring Machine, 3PH, Cleaned, Checked, Repaired

Vitap Alpha 27 Construction Boring Machine, 3PH, Cleaned, Checked, Repaired

Description:

VITAP ALFA 27 CONSTRUCTION BORING MACHINE27-Spindle boring head on 32 mm centers, drills vertically from bottom-up and head rotates to horizontal position for edge boring, head rotation is pneumatic with switch control.

2-3/4" Max. drilling depth

2.5 HP - 2,800 RPM motor

Pneumatic drill head advance with speed contro

Head height adjustment with mechanical digital readout

34" x 20" table size

Max. workpiece width 31-1/2"

Equipped with: Left & right side fences for construction boring

(3) pneumatic holddown clamps,

118" line boring fence w/ (4)flip-stops

Pneumatic foot pedal control.

Drilling spindles 27 32 mm grid

Drilling block pivotable Yes

Workpiece clamping pneumatic

Pneumatic clamping 3

Workpiece support plain table

Drilling depth adjustment Revolver-type stop

Space required Length 1.600 mm

Space required Width 1.300 mm

Space required Height 1.500 mm
